Nevalux L 710 LED Silver

ELDAS® no. 941 200 129

EAN-No. 4007841 053192

This product is being replaced by a successor product.

Go to successor product · L 710 S Anthracite (4007841053185)

Lighting meets the future. The L 710 LED sensor-switched outdoor light with warm white 3000 K captivates with its pioneering design and creates a unique light pattern with 670 lm and elegant light gradient. With intelligent 360° infrared mini sensor, manual override (4 h), four sensor programmes, including night-light functions as well as soft light start. Output: 8,6 W. Available in anthracite and silver.

Including STEINEL LED system
Intelligent soft light start
UV-resistant plastic
High-quality aluminium
Optional basic lighting level 10 %
4-hour manual override (optional)
Sensor with 4 intelligent programmes

Identification

Variant Silver

Variants

Luminous flux 670 lm

Dimensions

Dimensions L × W × H 260 x 140 x 77 mm

Electrical

Mains connection 220 – 240 V , 50 / 60 Hz

Power 8,6 W

Sensor technology

Max. mounting height 2,50 m

Sensor technology passive infrared

With motion detector Yes

Detection angle 360 °

Sneak-under protection Yes

Segment-by-segment masking Yes

Electronic scalability No

Mechanical scalability No

Tangential range r = 8 m (201 m²)

Connectivity

Networking No

Lighting technology

Colour temperature 3000 K

Colour rendering index 80-89

With illuminant Yes, STEINEL LED system

Illuminant LED cannot be replaced

Base without

LED cooling system Passive Thermo Control

Soft light start Yes

Continuous light selectable, 4h

Lifetime

LED lifetime max. °C 50000 h

Settings

Twilight switch Yes

Twilight setting 2 – 2000 lx

Time setting 5 sec – 15 min

Base light function Yes

With remote control No

Housing & material

Impact resistance IK03

Protection class (IP) IP44

Protection class II

Ambient temperature -20 – 40 °C

Housing material Aluminium

Cover material Plastic, opal

Cover material (scope of delivery) sticker

Scope of delivery & warranty

Manufacturer warranty 3 years

Sensor detection range

Data sheet User manual

LN 710 LED Silver

Item no. 4007841053178
