Nevalux RS PRO 5150 C without motion detector

Nevalux RS PRO 5150 C without motion detector

ELDAS® no. 941 375 589 · EAN-No. 4007841 058722

Technical data Illustrations Wiring diagrams Downloads
Nevalux Nevalux Connect

Nevalux RS PRO 5150 C without motion detector

ELDAS® no. 941 375 589

EAN-No. 4007841 058722

This product is being replaced by a successor product.

Go to successor product · RS PRO 5150 SC with motion detector & Bluetooth (058739)

Perfect for renovation. Our engineers agreed: The new moisture-proof luminaire should be simple and good. Easy to install and maintain, good in energy efficiency, function and quality. The result: RS PRO 5100 C. The moisture-proof luminaire the world has been waiting for. Robust, highly functional, child's play to install, wireless to network and ultimately convenient to adjust via smartphone.

  • Including STEINEL LED system
  • Interconnectable and adjustable via Bluetooth
  • Impact-resistant material rated to IK07
  • Optional basic lighting level 0 - 100 %
  • Adjustable main light brighness (0 - 100%)
  • Adjustable mounts for easy installation

Identification

Type of accessory Other

Dimensions

Dimensions L × W × H 1500 x 87 x 58 mm

Electrical

Mains connection 220 – 240 V / 50 – 60 Hz
Power 42 W
Own consumption 0,45 W

Sensor technology

With motion detector No

Connectivity

Networking Yes
Networking via Bluetooth Mesh Connect

Lighting technology

Measured luminous flux 360° 5940 lm
Colour temperature 4000 K
Illuminant LED cannot be replaced

Lifetime

LED lifetime max. °C 60000 h
LED lifetime L70B50 25°C > 60000 h
Luminous flux decline per LM80 L80B10

Settings

Twilight setting 2 – 2000 lx
Time setting 5 s – 60 Min.
Base light function Yes
Base light function time 1-60 min
Main light adjustable 0 - 100 %
Functions Encrypted communication\nNeighbouring group function\nFree selection of the light value in a luminaire group\nAdjustable fade time when switching on and off\nConnection to central battery systems
Base light function in percent 0 – 100 %
Base light function percent from 0 %

Housing & material

Impact resistance IK07
Protection class (IP) IP65
Protection class II
Ambient temperature -20 – 40 °C
Housing material Plastic
Cover material Plastic, structured
Mounting location ceiling wall
Material Plastic
Colour grey

Scope of delivery & warranty

Manufacturer warranty 5 years

Certificates & EPREL

Certificates DEKRA
EPREL category Surrounded product with integrated light source

Technical drawing

Sensor detection range

Wiring diagram 1
