Nevalux FRS 20 LED
ELDAS® no. 924 324 219
EAN-No. 4007841 747619
This product is being replaced by a successor product.
Go to successor product · RS PRO P2 S warm white (056100)Practical and thrifty. FRS 20 high-frequency utility room light, ideal for garages, narrow corridors, basements and boiler rooms, 360° angle of coverage, infinitely variable and electronically controlled reach from 1 - 5 m, selectable time and twilight threshold, impact-resistant, includes low-energy lamp.
- Including STEINEL LED system
- Impact-resistant material rated to IK07
- UV-resistant plastic
Variants
Luminous flux
700 lm
Dimensions
Dimensions L × W × H
195 x 300 x 53 mm
Electrical
Mains connection
220 – 240 V , 50 / 60 Hz
Power
12,5 W
Switching output 1 resistive
200 W
Sensor technology
Sensor technology
High frequency
Transmission power
< 1 mW
With motion detector
Yes
Detection
also through glass, wood and stud walls
Detection angle
360 °
Opening angle
160 °
Electronic scalability
Yes
Mechanical scalability
No
Lighting technology
Colour temperature
3000 K
LED colour deviation
SDCM3
Colour rendering index
80-89
With illuminant
Yes, STEINEL LED system
Illuminant
LED cannot be replaced
Base
without
LED cooling system
Passive Thermo Control
Luminous flux
700 lm
Lifetime
LED lifetime max. °C
50000 h
Luminous flux decline per LM80
L70B10
Settings
Twilight switch
Yes
Twilight setting
2 – 2000 lx
Time setting
5 sec – 15 min
Housing & material
Impact resistance
IK07
Protection class (IP)
IP54
Protection class
II
Ambient temperature
-10 – 40 °C
Housing material
Plastic
Cover material
Plastic, opal
Scope of delivery & warranty
Manufacturer warranty
3 years
