Identification
Variant
DALI - silver
Version
Presence detector
Dimensions
Dimensions L × W × H
80 x 80 x 21 mm
Electrical
Mains connection
230 V, 50 / 60 Hz
Supply voltage detail
DALI bus
Control output DALI
Broadcast 2x12 electronic ballasts
Sensor technology
Sensor technology
passive infrared
Detection angle
180 °
Opening angle
90 °
Sneak-under protection
Yes
Electronic scalability
Yes
Mechanical scalability
No
Radial range
r = 4 m (25 m²)
Tangential range
r = 20 m (628 m²)
Switching zones
96 switching zones
Presence range
r = 4 m (25 m²)
Optimal mounting height
1,2 m
Connectivity
Lighting technology
Constant light regulation
Yes
Settings
Twilight setting
2 – 1000 lx
Time setting
30 sec – 30 min
Base light function
Yes
Base light function time
1-30 min, all night
With remote control
No
Twilight setting teach
Yes
Base light function in percent
10 – 50 %
Housing & material
Protection class (IP)
IP20
Ambient temperature
0 – 40 °C
Mounting location
wall
Application location
Indoors
Mounting type
Concealed wiring
Material
Plastic
Colour
Silver
RAL colour
9006
Scope of delivery & warranty
Manufacturer warranty
5 years
Other
Application, location, room
One-person office, corridor, aisle, side room, stairwell, washroom, wc, equipment room
