Identification
Version
Presence detector
Dimensions
Dimensions L × W × H
55 x 77 x 77 mm
Electrical
Supply voltage detail
KNX bus
Sensor technology
Max. mounting height
4,00 m
Sensor technology
passive infrared
With motion detector
Yes
Detection angle
360 °
Opening angle
71 °
Sneak-under protection
Yes
Segment-by-segment masking
No
Electronic scalability
No
Mechanical scalability
No
Range detail
Retina lens and hexagonal Fresnel structure
Radial range
4 x 4 m (16 m²)
Tangential range
4 x 4 m (16 m²)
Switching zones
260 switching zones
Mounting height
2,50 – 4 m
Presence range
4 x 4 m (16 m²)
Optimal mounting height
2,8 m
Connectivity
Networking
Yes
Type of networking
Master/master\nMaster/slave
Networking via
KNX bus
KNX functions
Photo-cell controller\nBasic light level function\nLight level\nHVAC output\nConstant-lighting control\nLight output 4x\nPresence output\nDay / night function\nLogic gate
With bus coupler
Yes
Lighting technology
Soft light start
Yes
Continuous light
selectable
Constant light regulation
No
Settings
Twilight switch
Yes
Twilight setting
10 – 1000 lx
Time setting
10 s – 1092 Min.
Base light function
Yes
Main light adjustable
0 - 100 %
Settings via
ETS software\nRemote control\nBus\nSmart Remote
With remote control
No
Twilight setting teach
Yes
Housing & material
Protection class (IP)
IP20
Protection class
II
Ambient temperature
from 0 up to 40 °C
Mounting location
ceiling
Application location
Indoors
Mounting type
In-ceiling installation
Material
Plastic
Application room
Indoors
WC / washroom
care room
function room / ancillary room
hotel room
one-person office
Colour
white
RAL colour
9010
Scope of delivery & warranty
Manufacturer warranty
5 years
Corner wall bracket included
No
