Identification
Variant
KNX - round
Version
Presence detector
Model
KNX
Dimensions
Dimensions Ø × H
94 x 48,6 mm
Electrical
Supply voltage detail
KNX bus
Sensor technology
Sensor technology
passive infrared
Detection angle
360 °
Opening angle
160 °
Sneak-under protection
Yes
Segment-by-segment masking
No
Electronic scalability
No
Mechanical scalability
No
Range detail
Retina lens and hexagonal Fresnel structure
Radial range
4 x 4 m (16 m²)
Tangential range
4 x 4 m (16 m²)
Mounting height
2,50 – 4,00 m
Presence range
4 x 4 m (16 m²)
Optimal mounting height
2,8 m
Connectivity
Networking
Yes
Type of networking
Master/slave, Master/master
KNX functions
Light output 4x, Presence output, Light level, Constant-lighting control, Basic light level function, HVAC output
With bus coupler
Yes
Settings
Twilight setting
10 – 1000 lx
Time setting
60 sec – 60 min
Base light function time
Permanently ON, 1-255 min, all night
Settings via
ETS software, Remote control, Bus
Twilight setting teach
Yes
Base light function in percent
10 – 50 %
Housing & material
Protection class (IP)
IP20
Ambient temperature
0 – 40 °C
Mounting location
ceiling
Application location
Indoors
Mounting type
Concealed wiring
Material
Plastic
Colour
white
RAL colour
9010
Scope of delivery & warranty
Manufacturer warranty
5 years
Other
Application, location, room
classroom, One-person office, side room
