Nevalux MotionSwitch LED Z-Wave

EAN-No. 4007841 035402

Discontinued

This product is being discontinued and is available while stocks last. No successor product has been announced yet.

Smart home via power socket. No cable. No batteries. No stress. The MotionSwitch LED Z-Wave is a motion detector, brightness sensor, button and orientation light in one. Above all, it is easy to integrate and operate: plug into the power socket, install via the Smart Friends app and control indoor lights, roller-shutter motors, sound systems, alarm systems etc. easily and conveniently.

Smart home via power socket. No cable. No batteries. No stress. The MotionSwitch LED Z-Wave is a motion detector, brightness sensor, button and orientation light in one. Above all, it is easy to integrate and operate: plug into the power socket, install via the Smart Friends app and control indoor lights, roller-shutter motors, sound systems, alarm systems etc. easily and conveniently.

Identification

Version Motion detectors

Dimensions

Dimensions L × W × H 56 x 55 x 55 mm

Electrical

Mains connection 230 – 240 V / 50 Hz

Power 1,5 W

Own consumption 0,3 W

Sensor technology

Max. mounting height 1,10 m

Sensor technology passive infrared

With motion detector Yes

Detection angle 180 °

Opening angle 90 °

Sneak-under protection Yes

Segment-by-segment masking No

Electronic scalability No

Mechanical scalability No

Radial range r = 4 m (25 m²)

Tangential range r = 20 m (628 m²)

Mounting height 0,20 – 1,10 m

Optimal mounting height 1,1 m

Connectivity

Networking Yes

Networking via Wireless

Lighting technology

Soft light start No

Constant light regulation No

Settings

Twilight switch Yes

Twilight setting 2 – 2000 lx

Time setting 5 s – 15 Min.

Base light function Yes

Main light adjustable No

Functions Sensor channel\nOrientation light

Settings via Z-Wave\nPotentiometers

With remote control No

Twilight setting teach No

Housing & material

Protection class (IP) IP20

Ambient temperature -10 – 35 °C

Housing material Plastic

Mounting location wall

Application location Indoors

Mounting type Other

Material Plastic

Application room Indoors WC / washroom function room / ancillary room

Colour white

RAL colour 9010

Scope of delivery & warranty

Manufacturer warranty 3 years

Corner wall bracket included No

Certificates & EPREL

Certificates VDE

Technical drawing

Sensor detection range
