Nevalux RS LED D1
ELDAS® no. 941 300 459
EAN-No. 4007841 052522
This product is being replaced by a successor product.
Go to successor product · RS PRO Connect R20 Q warm white (4007841057183)Radiant eye-catcher. STEINEL high-frequency sensor-switched indoor light RS LED D1 with chrome-plated metal surround, ideal for corridors, hallways, stairwells and bathrooms. STEINEL LED lighting system, 9,5 W with 795 lm, 360° high-frequency sensor with 3-8 m reach, switches light ON without a sound, with ambient light, Night-light function and 4-hour manual override (3000 K).
- Including STEINEL LED system
- LED ambient light
- Optional basic lighting level 10 %
- 4-hour manual override (optional)
- High-quality materials
Variants
Luminous flux
795 lm
Dimensions
Dimensions L × W × H
300 x 300 x 65,5 mm
Electrical
Mains connection
220 – 240 V , 50 / 60 Hz
Power
9,5 W
Sensor technology
Sensor technology
High frequency
With motion detector
Yes
Detection
also through glass, wood and stud walls
Detection angle
360 °
Opening angle
160 °
Electronic scalability
Yes
Mechanical scalability
No
Connectivity
Networking
No
Lighting technology
Colour temperature
3000 K
LED colour deviation
SDCM3
Colour rendering index
80-89
With illuminant
Yes, STEINEL LED system
Illuminant
LED cannot be replaced
Base
without
LED cooling system
Passive Thermo Control
Soft light start
Yes
Continuous light
selectable, 4h
Luminous flux
795 lm
Lifetime
LED lifetime max. °C
50000 h
Settings
Twilight switch
Yes
Twilight setting
2 – 2000 lx
Time setting
5 sec – 15 min
Base light function
Yes
Base light function time
10/30 min, all night
Housing & material
Impact resistance
IK00
Protection class (IP)
IP20
Protection class
II
Ambient temperature
-10 – 40 °C
Housing material
Plastic
Cover material
Plastic, opal
Scope of delivery & warranty
Manufacturer warranty
3 years
