Nevalux sensIQ S inox

ELDAS® no. 535 940 630

EAN-No. 4007841 034962

This product is being replaced by a successor product.

Go to successor product · sensIQ S white (034955)

The evolution of perfection. The sensIQ S is just as perfect as its larger role model. For indoors and outdoors, ideal for building entrances, loading bays, for mounting heights of up to 5 m, quadruple sensor system for optimum surveillance over 3x100° coverage angle, 20 m reach (tangential), reach setting to the accuracy of a metre in 3 independent directions. Remote control and corner wall mount bracket included.

4x pyro system
UV-resistant plastic
Including corner wall mount
Remote control RC9 included
Smart Remote remote control optional

Identification

Variant inox

Version Motion detectors

Type of accessory Corner adapter

Dimensions

Dimensions L × W × H 114 x 74 x 128 mm

Electrical

Mains connection 100 – 240 V , 50 / 60 Hz

Switching output 1 resistive 2000 W

Supply voltage detail 500 VA max., 120 V

Sensor technology

Sensor technology passive infrared

Detection angle 300 °

Opening angle 90 °

Sneak-under protection Yes

Segment-by-segment masking Yes

Electronic scalability No

Mechanical scalability Yes

Range detail Reach adjustable from 2 - 20 m in 3 directions (100° in each)

Radial range r = 4 m (42 m²)

Tangential range r = 20 m (1047 m²)

Switching zones 1360 switching zones

Mounting height 2,00 – 5,00 m

Optimal mounting height 2 m

Connectivity

Networking Yes

Lighting technology

Constant light regulation No

Settings

Twilight setting 2 – 2000 lx

Time setting 5 sec – 15 min

Base light function No

With remote control Yes

Twilight setting teach Yes

Housing & material

Protection class (IP) IP54

Ambient temperature -20 – 50 °C

Mounting location corner wall

Application location Indoors Outdoors

Mounting type Surface wiring

Material Plastic

Colour Silver

Scope of delivery & warranty

Manufacturer warranty 5 years

Certificates & EPREL

Certificates VDE

Sensor detection range

Data sheet User manual

Remote control RC9

Item no. 4007841007638

Remote control Smart Remote

Item no. 009151
