Nevalux XLED home 2 Z-Wave graphite

EAN-No. 4007841 033996

Discontinued

This product is being discontinued and is available while stocks last. No successor product has been announced yet.

Top seller. Now even better. XLED home 2 Z-Wave sensor-switched outdoor floodlight for even more safety and security. Can be integrated into the Smart Friends system or any other Z-Wave network. Fully swivelling LED panel in classy stainless-steel look. For the most exacting of demands on design and maximum lighting convenience. 1184 lm at a power consumption of only 14,8 W. Swivelling precision IR sensor (horizontally: 180°, vertically: 90°). 140° angle of coverage, 14 m reach. High thermal conductivity magnesium composite cooling system (HCMC).

Including STEINEL LED system
HCMC cooling system
UV-resistant plastic
Colour rendering index Ra =80

Identification

Variant graphite

Variants

Luminous flux 1184 lm

Dimensions

Dimensions L × W × H 194 x 180 x 161 mm

Electrical

Mains connection 230 – 240 V , 50 / 60 Hz

Power 14,8 W

Sensor technology

Sensor technology passive infrared

With motion detector Yes

Detection angle 140 °

Sneak-under protection Yes

Segment-by-segment masking Yes

Tangential range r = 14 m (239 m²)

Transmission range Up to 100 m in the open, 30 m indoors

Lighting technology

Colour temperature 4000 K

LED colour deviation SDCM3

Colour rendering index 80-89

With illuminant Yes, STEINEL LED system

Illuminant LED cannot be replaced

LED cooling system HCMC (High Conductive Magnesium Composite)

Luminous flux 1184 lm

Lifetime

LED lifetime max. °C 50000 h

Luminous flux decline per LM80 L70B10

Settings

Twilight switch Yes

Twilight setting 2 – 2000 lx

Time setting 8 sec – 35 min

Housing & material

Impact resistance IK00

Protection class (IP) IP44

Protection class II

Housing material HCMC

Cover material Plastic, opal

Scope of delivery & warranty

Manufacturer warranty 5 years

Sensor detection range

Data sheet User manual

Smartfriends Box

Item no. 4007841029876
