Identification
Version
Presence detector
Dimensions
Dimensions L × W × H
50 x 80 x 80 mm
Electrical
Mains connection
21 – 30 V
Sensor technology
Max. mounting height
1,20 m
Sensor technology
passive infrared
With motion detector
Yes
Detection angle
180 °
Opening angle
90 °
Sneak-under protection
Yes
Segment-by-segment masking
No
Electronic scalability
Yes
Mechanical scalability
No
Radial range
r = 4 m (25 m²)
Tangential range
r = 12 m (226 m²)
Switching zones
96 switching zones
Mounting height
1,0 – 1,2 m
Presence range
r = 4 m (25 m²)
Optimal mounting height
1,2 m
Connectivity
Networking
Yes
Type of networking
Master/Slave, Master/Master
KNX functions
Photo-cell controller
Basic light level function
Light level
HVAC output
Constant-lighting control
Light output 4x
Air pressure
Humidity output
Presence output
Day / night function
Dewpoint
Temperature output
Logic gate
With bus coupler
Yes
Networking via
KNX bus
Lighting technology
Soft light start
Yes
Continuous light
selectable
Constant light regulation
Yes
Settings
Twilight switch
Yes
Twilight setting
2 – 1000 lx
Time setting
60 s – 255 min
Base light function
Yes
Main light adjustable
0 - 100 %
Functions
Presence detector logic
Settings via
ETS software, Remote control, Smart Remote
With remote control
Yes
Twilight setting teach
Yes
Housing & material
Protection class (IP)
IP20
Ambient temperature
0...+40 °C
Mounting location
Wall
Application location
Indoors
Mounting type
Concealed mounting
Material
Plastic
Application room
Indoors, WC / washroom, corridor / aisle, function room / ancillary room, kitchenette, one-person office, stairwell
Colour
White
RAL colour
9010
Scope of delivery & warranty
Manufacturer warranty
5 years
Corner wall bracket included
No
Certificates & EPREL
