Steinel RS PRO 6100 circular SC with motion detector

ELDAS® no. 941 622 309

EAN-No. 4007841 089832

Our RS PRO 6100 circular SC luminaire is pioneering in terms of efficiency and sustainability. The low-maintenance, modular luminaire is made from up to 98% recycled plastic. Should components designed for a particularly long service life, such as the sensor, power supply unit or LED board, ever fail, they can be replaced. The basic lighting function and intelligent sensor technology reduce the operating times of the lighting components, further increasing their service life. Whether in industrial environments, car parks and underground garages or in storage and basement areas – the wide beam angles always guarantee maximum light output. And the intelligent sensor technology, in conjunction with Connected Lighting via Bluetooth, always ensures maximum energy efficiency. And to close the circle, thanks to the take-back concept, every luminaire is returned to the material cycle at the end of its long product life. You have our word!

Long field luminaire, 1200 mm, with integrated digital high-frequency sensor
Ideal for renovating car parks, halls or garages
Up to 98% recycled plastic
360° motion detection with ø8 m range, 5-wire through-wired
Precise adjustment of range and sensitivity
Excellent repairability: power supply unit, sensor and LED card replaceable
Robust with IP65 protection class and IK08 impact resistance
All settings and networking easily managed via the free Steinel Connect app
Suitable for connection to a central battery

Dimensions

Dimensions L × W × H 1200 x 90 x 80 mm

Electrical

Mains connection 220 – 240 V / 50 – 60 Hz

Power 31 W

Own consumption 0,3 W

Sensor technology

Max. mounting height 3,50 m

Sensor technology High frequency

Transmission power < 1 mW

HF technology 24 GHz

With motion detector Yes

Detection angle 360 °

Opening angle 160 °

Electronic scalability Yes

Mechanical scalability No

Radial range Ø 8 m (50 m²)

Tangential range Ø 8 m (50 m²)

Mounting height 2 – 3,50 m

Optimal mounting height 2,8 m

Connectivity

Networking Yes

Type of networking Master/master

Networking via Bluetooth Mesh

Slave mode adjustable Yes

Lighting technology

Colour temperature 4000 K

LED colour deviation SDCM3

With illuminant Yes, STEINEL LED system

Illuminant LED can be replaced

Base without

LED cooling system Passive Thermo Control

Soft light start Yes

Continuous light selectable

Settings

Twilight switch Yes

Twilight setting 2 – 2000 lx

Time setting 5 s – 60 Min.

Base light function Yes

Base light function time 5s-60 min Brightness-controlled

Main light adjustable 0 - 100 %

Functions Motions sensor DIM function Dimmkurve individuell einstellbar Adjustable fade time when switching on and off Semi-/fully automatic Light sensor Neighbouring group function Encrypted communication Timer

Settings via App Bluetooth Bluetooth Mesh

With remote control No

Twilight setting teach Yes

Base light function in percent 10 – 100 %

Base light function percent from 10 %

Housing & material

Impact resistance IK08

Protection class (IP) IP65

Protection class I

Ambient temperature from -20 up to 40 °C

Housing material Plastic

Cover material PC structured

Mounting location ceiling wall

Application location Indoors

Mounting type Surface wiring

Application room WC / washroom changing room corridor / aisle function room / ancillary room multi-storey / underground car park production facilities stairwell warehouse

Colour grey

Scope of delivery & warranty

Manufacturer warranty 5 years

Certificates & EPREL

EPREL category Surrounded product with integrated light source

Technical drawing

Sensor detection range

Wiring diagram 1

Light with neutral conductor

Data sheet User manual Declaration of conformity Product brochure LDT file (light distribution)
